Laser cutting machine power and plate thickness

Laser cutting machine power and plate thickness are more important in the use of laser cutting machine. Only by knowing how much power can cut how large the metal plate is, can we better cut the plate and avoid some operating errors that lead to waste of manpower and material resources. Let's talk about lasers of various powers and plate cutting. The power and plate thickness of laser cutting machine are as follows:

Low-power laser cutting machine

Usually we call laser cutting machines below 1000W-6000W low-power laser cutting machines. At this time, the thickness range of laser cutting materials is:

1000W cutting carbon steel thickness: 0.8-10mm; cutting stainless steel thickness: 0.8-5mm; aluminum alloy: 0.8-3mm; brass: 1-3mm

1500W cutting carbon steel thickness: 1-16mm; cutting stainless steel thickness: 1-6mm; aluminum alloy: 1-4mm; brass: 1-3mm

200 0W cutting carbon steel thickness: 1-20mm; cutting stainless steel thickness: 1-8mm; aluminum alloy: 1-6mm; brass: 1-5mm

3000W-3300W cutting carbon steel thickness: 1-22mm; cutting stainless steel thickness: 1-10mm; aluminum alloy: 1-8; brass: 1-6mm

4000W cutting carbon steel thickness: 1-25mm; cutting stainless steel thickness: 1-15mm; aluminum alloy: 1-10mm; brass: 1-8mm

6000W cutting carbon steel thickness: 1-30mm; cutting stainless steel thickness: 1-20mm; aluminum alloy: 1-20mm; brass: 1-12mm

There is something called the top value of cutting, which means that the peak of the cutting power is the number behind it. Usually, the machine will not be put in this state, because the cutting incision will more or less hang slag, so the right power to cut the right thickness is the right choice. Next, let’s take a look at the cutting thickness of the 8000-15000W laser cutting machine.

High-power laser cutting machine

8000W cutting carbon steel thickness: 1-40mm; cutting stainless steel thickness: 1-30mm; aluminum alloy: 1-30mm; brass: 1-16mm

10000W cutting carbon steel thickness: 1-45mm; cutting stainless steel thickness: 1-40mm; aluminum alloy: 1-40mm; brass: 1-20mm

12000W cutting carbon steel thickness: 1-50mm; cutting stainless steel thickness: 1-45mm; aluminum alloy: 1-45mm; brass: 1-20mm

15000W cutting carbon steel thickness: 1-60mm; cutting stainless steel thickness: 1-50mm; aluminum alloy: 1-40mm; brass: 1-20mm

The above are the parameters of 1000-12000W laser cutting machine power and plate thickness, which may not be accurate. The actual situation will be slightly different, but it will not be far off. Our Ritman Laser 1000-20000W laser cutting machine has a solid body, is firm and not easy to deform. It has been adopted by many customers and is running well. If you have any needs, you can visit our factory. You are welcome to come.
