How thick can a 3000w metal optical fiber laser cutting machine cut?
The 3000w laser cutting machine can cut a wide range of thicknesses. Specifically, for carbon steel, the maximum thickness can reach 20mm to 25mm; for stainless steel, the maximum thickness can reach 10mm to 12mm; and for aluminum and copper plates, the maximum thickness is usually 8mm.
Mainly depends on the power performance of the cutting machine. Generally speaking, low-power laser cutting machines can cut steel plates with a thickness range of 0.8-10mm, while high-power laser cutting machines can cut steel plates with a thickness range of 1-30mm.
Specifically, a 500W fiber laser cutting machine can cut carbon steel with a maximum thickness of 6mm, stainless steel with a maximum thickness of 3mm, and aluminum and copper plates with a maximum thickness of 2mm.
And a 1000W fiber laser cutting machine can cut carbon steel with a maximum thickness of 10mm, stainless steel with a maximum thickness of 5mm, and aluminum and copper plates with a maximum thickness of 3mm.
For a 2000W fiber laser cutting machine, the maximum thickness of carbon steel can reach 16mm, the maximum thickness of stainless steel is 8mm, and the maximum thickness of aluminum and copper plates is 5mm.
In addition, for higher power laser cutting machines, such as 3000W and 4000W, the thickness of steel plates they can cut is about 1-22mm and 1-25mm respectively.
The 6000W laser cutting machine can cut carbon steel with a maximum thickness of about 30mm, and the maximum thickness of stainless steel can reach about 20mm.
It should be noted that the cutting capacity of the laser cutting machine is also affected by many factors, such as the brand, quality, application environment, speed, etc. of the cutting machine. Therefore, in actual applications, the cutting thickness may vary, and it is necessary to select and consider according to specific needs.
